Vehicle Bridge Wireless Load Monitoring System Based on Polynomial Regression

Volume 7, Issue 3

Views: 0 Downloads: 0

Vehicle Bridge Wireless Load Monitoring System Based on Polynomial Regression
Vehicle Bridge Wireless Load Monitoring System Based on Polynomial Regression
University of Shanghai for Science and Technology, Shanghai, 200093, China
Vol. 7, Issue 3, Pages: 127-133(2026)
Published：30 March 2026
DOI：10.47297/taposatWSP2633-456926.20260703
Accepted：

Scan QR Code

Yu Wang.Vehicle Bridge Wireless Load Monitoring System Based on Polynomial Regression[J].Theory and Practice of Science and Technology,2026,07(03):127-133.
DOI：

Yu Wang.Vehicle Bridge Wireless Load Monitoring System Based on Polynomial Regression[J].Theory and Practice of Science and Technology,2026,07(03):127-133. DOI： 10.47297/taposatWSP2633-456926.20260703.

摘要

Abstract

Overloading of vehicles is a common phenomenon in society

exhibiting high concealment during normal operation and thus being difficult to detect. Therefore

this paper proposes a novel load collection and wireless communication system that integrates wireless communication and machine learning to achieve real-time load prediction for small freight vehicles. The system is based on radio frequency (RF) communication. It collects axle stress data from the freight vehicle

transmits the acquired data wirelessly to a receiver

and then forwards it to the on-board computer via Controller Area Network (CAN) communication. Ultimately

a machine learning model is employed to predict the vehicle load

thereby enabling load monitoring. The proposed method is based on a lightweight algorithmic model. Considering the requirements for long-term operation

a low-power design is implemented to minimize deployment costs while ensuring fundamental computational capability. By employing a polynomial regression prediction algorithm and evaluating its overall performance on a real-world load dataset

the optimal data collection points are identified. Experimental validation demonstrates that the mean squared error of the prediction results is 0.3149

and the cross-validation score reaches 0.9233. Furthermore

the maximum error within the 95% confidence interval accounts for only 1.658% of the maximum axle load. These results confirm the system's capability to accurately predict actual load data.

关键词

Keywords

references

B. K. Rajak, S. Chatterjee, A. Upadhyay and M. V. Rani, "Contextual Difference in the Drivers of Internet-of-Things-Adoption in Road, Rail, and Maritime Freight Transport," in IEEE Transactions on Engineering Management, vol. 71 , pp. 11125 - 11137 , 2024 .

A. Onat and B. T. Kayaalp, "A Novel Methodology for Dynamic Weigh in Motion System for Railway Vehicles With Traction," in IEEE Transactions on Vehicular Technology, vol. 68 , no. 11 , pp. 10545 - 10558 , Nov. 2019 .

B. Allotta, P. D'Adamio, L. Marini, E. Meli, L. Pugi and A. Rindi, "A New Strategy for Dynamic Weighing in Motion of Railway Vehicles," in IEEE Transactions on Intelligent Transportation Systems, vol. 16 , no. 6 , pp. 3520 - 3533 , Dec. 2015 .

Z. Zhang, Y. Huang, R. Bridgelall, M. Al-Tarawneh and P. Lu, "Optimal System Design for Weigh-In-Motion Measurements Using In-Pavement Strain Sensors," in IEEE Sensors Journal, vol. 17 , no. 23 , pp. 7677 - 7684 , 1 Dec.1, 2017.

Z. Dong, H. Song, X. Ma, Y. Li and D. Wang, "Intelligent Weigh-in-Motion System Using Embedded MEMS Sensors for Pavement Monitoring," in IEEE Transactions on Instrumentation and Measurement, vol. 73 , pp. 1 - 11 , 2024, Art no. 2530411.

Chen Z ,Xie Z , Zhang J .Measurement of Vehicle-Bridge-Interaction force using dynamic tire pressure monitoring[J].Mechanical Systems & Signal Processing, 2018.

T. Yang et al., "Temperature-Compensated Multifunctional All-Fiber Sensors for Precise Strain/High-Pressure Measurement," in Journal of Lightwave Technology, vol. 37 , no. 18 , pp. 4634 - 4642 , 15 Sept.15, 2019.

J. Li et al., "Deformation and Load Detection of Wing Structure Based on Load-Strain Linear Superposition," in IEEE Transactions on Instrumentation and Measurement, vol. 74 , pp. 1 - 11 , 2025, Art no. 7005611.

Z. Li, C. Liu and C. Chigan, "VehicleView: a universal system for vehicle performance monitoring and analysis based on VANETs," in IEEE Wireless Communications, vol. 19 , no. 5 , pp. 90 - 96 , Oct. 2012 .

P. Zhang, X. Chen, S. Li, C. Zhang and Y. Hu, "Development of the Internet of Smart Orchard Things Based on Multi-Sensors and LoRa Technology," in Intelligent and Converged Net works, vol. 4 , no. 4 , pp. 342 - 354 , December 2023.

G. Premsankar, B. Ghaddar, M. Slabicki and M. D. Francesco, "Optimal Configuration of LoRa Networks in Smart Cities," in IEEE Transactions on Industrial Informatics, vol. 16 , no. 12 , pp. 7243 - 7254 , Dec. 2020 .

N. Zhao, Y. Wang, C. Zhang, X. Gao, Z. Wang and G. Ding, "Research Progress of High-Temperature Thin-Film Strain Gauges: A Review," in IEEE Sensors Journal, vol. 25 , no. 8 , pp. 12559 - 12577 , 15 April15, 2025.

G. Pasolini, "On the LoRa Chirp Spread Spectrum Modulation: Signal Properties and Their Impact on Transmitter and Receiver Architectures," in IEEE Transactions on Wireless Communications, vol. 21 , no. 1 , pp. 357 - 369 , Jan. 2022 .

J. N. V. R. Swarup Kumar, K. Venkateswararao, U. Ghugar, S. Kumar Bhoi and K. S. Sahoo, "Enhanced Connectivity for Non-Critical In-Vehicle Systems Using EnRF24L01," in IEEE Sensors Journal, vol. 25 , no. 7 , pp. 11955 - 11962 , 1 April1, 2025

Z. Li, J. Zhang and S. Hu, "Incremental support vector machine algorithm based on multi-kernel learning," in Journal of Systems Engine ering and Electronics, vol. 22 , no. 4 , pp. 702 - 706 , Aug. 2011 .

S. Kishore, S. K. Bharti, P. Anand, D. Srivastav and S. Sonali, "Temperature Prediction for Electric Vehicles Using Machine Learning Algorithms," in IEEE Transactions on Industry Applications, vol. 60 , no. 6 , pp. 9251 - 9259 , Nov.-Dec. 2024.
